VEHICLE SPECIFICATION |
DESCRIPTION |
Truck Model |
ZZ4257N3247V |
Type of Vehicle |
TRACTOR TRUCK |
Truck Brand |
SINOTRUK—HOWO |
Driving Position |
Left hand Driving |
Fuel tanker capacity |
400L |
The Total Mass |
40,000kg |
Dead Weight |
8800kg |
Max speed |
102km/h |
Color |
Optional |
Chassis & Add Components |
|
Frame Details |
High-Strength U-profile ladder frame with Section of 300*90*8mm and reinforced sudfram, all cold riveted cross members. |
Dimension(L×W×H)(unloaded) |
6800x2496x3563mm |
Approaching angle/Departure angle |
16/70 |
Overhang(front/rear) |
1500/725mm |
Wheel base |
3225+1350mm |
Engine |
|
Model |
WD615.47 |
Power |
371hp/272kw.2000r/min |
Emission |
EURO II |
Cylinder bore*stroke |
126*155mm |
Displacement |
9.876L |
Type |
water-cooled,four strokes,6 cylinders in line, turbocharged, directly injection. |
Kind of Fuel |
Diesel |
Fuel Consumption |
30L/100km |
Clutch & Gear Box System |
|
Battery |
2X12V/165Ah |
Alternator |
28V-1500kw |
Starter |
7.5Kw/24V |
Brake System |
|
Service brake |
Dual circuit compressed air brake |
Parking brake |
Spring energy, compressed air Operating on rear wheels |
Auxiliary brake |
Engine exhaust brake |
Wheels & Tyres |
|
Type |
295/80R22.5 |
Material |
Tubeless tires |
Quantity |
10+1 spare |
King pin |
90mm |
Cabin |
|
Type |
HW76 Standard cabin |
Single sleeper with air conditioner, all-steel forward control,55 hydraulically tiltable To the front,2- arm windscreen wiper system with three speeds, laminated windscreen With casted-in radio aerial,hydraulically damped adjustable driver’s seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers. |
