Model |
ZZ4187M3517 Left Hand Driving |
||
Brand |
SINOTRUK-HOWO |
||
Dimension(Lx W xH)(unloaded)(mm) |
6110x2496x3563 |
||
Approaching/Departure angle(°) |
16/42 |
||
Overhang(front/rear) (mm) |
1500/1110 |
||
Wheel base (mm) |
3500 |
||
Max speed(km/h) |
102 |
||
Curb weight(kg) |
7210 |
||
Engine (Steyr technology) |
Brand |
SINOTRUK |
|
Model |
water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection |
||
Fuel type |
Diesel |
||
Horse Power |
290HP |
||
Emission |
EURO II |
||
Fuel tanker capacity(L) |
400L |
||
Transmission |
Model |
HW13710CL,10-Forward, 2-Reverse |
|
Brake system |
Service brake |
Dual circuit compressed air brake |
|
Parking brake |
spring energy, compressed air operating on rear wheels |
||
Auxiliary brake |
Engine exhaust brake with |
||
Steering system |
Model |
hydraulic steering with power assistance |
|
Front axle |
HF7, 7000kg |
||
Rear axle |
ST16, 16000kg |
||
Color |
Optional |
||
Tire |
295/80R22.5 |
||
Electrical system |
Battery |
2X12V/165Ah |
|
Alternator |
28V-1500kw |
||
Starter |
7.5Kw/24V |
||
Cab |
HOWO76 cab, one sleeper, with air conditioner. all-steel forward control, 55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers |
