  • Sino Truck 6x4 Tipper Truck 336hp For Sale
Product name : Sino Truck 6x4 Tipper Truck 336hp For Sale
Product No. : ZZ3257N3647D1
1 : Horse power - 336hp
2 : Drive Model -6x4
3 : Payload -35t
4 : Cargo Box Size -5400mmx2300mmx1500mm
5 : Tires-12.00R20
←[Previous Product]              [Next Product]→
Details:
Sino Truck 6x4 Tipper Truck 336hp For Sale

Major Parameter



Road Type

Paved road

Max weight(t)

≤50

Upper body Dimension

5400×2300×1500mm

Cruising speed/Max speed

40-50/78(Km/h)

Vehicle model

ZZ3257N3647D1

Rated Load(ton)

35

Capacity of the fuel tank

300L




Engine

Frame Specification

Engine type

WD615.69

Frame(mm)

8+5/300

Emission standard

Euro II

Dimensions(mm)

8329*2496*3450

Displacement

9.726L

Wheel base (mm)

3625+1350

Rated Power / rotating

250Kw/2200rpm

Front Suspension

1500

Maximum Torque

1500Nm

Rear Suspension

1670

Fuel type

Diesel

Approach/Departure angel

19/26

Transmission

Axle

Type

HW19710

Front axle

HR9

Torque

1900Nm

Disc Brake

Input power

285Kw

Rear axle

AC16

Weight

285kg

Dump Brake

Oiling quantity

12

Speed ratio

4.77

 Cab (HW76, mid-lengthened flat roof)

Equipments

One sleeping bed

Automatic air conditioning

Mechanical clerestory

Hydraulic suspension of cab

Hydraulic driver seat with seatbelts

radio with MP3 player

  Steering system

Power steering

  Clutch

φ430

  Tire

12.00R20

Wheels number

10+1
