Cabin |
Driving type 4x2 LHD/RHD |
|
|
1880 Cabin, bed, AC, wind deflector, power window, central lock is optional |
||
|
Overall Dimensions |
5995×2150×2450 mm |
|
|
Wheel Base |
3360 mm |
|
|
GVW |
4495kg |
|
|
Front Axle |
2 ton |
|
|
Rear Axle |
3.5 ton |
|
|
Engine |
Brand |
YUNNEI |
|
Model |
4100 |
|
|
Type |
4-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection |
|
|
Displacement |
3.76L |
|
|
Horse Power (HP) |
110 |
|
|
Emission standard |
Euro II / other standard engine is optional |
|
|
Max Speed |
90 km/h |
|
|
Tire |
7.00R16 |
|
|
Transmission |
WLY6T100 |
|
|
Oil Tank |
120L |
|
|
Cargo Dimensions |
3850x2050x400 mm |
|
|
Brake System |
Service brake:dual circuit compressed air brake |
|
|
Parking brake (emergency brake):spring energy,compressed air operating on rear wheels |
||
|
Auxiliary brake:engine exhaust valve brake |
||
|
Electrics |
Operating voltage:24V,negative grounded |
|
|
horn,headlamps,fog lights,brake lights,indicators and reverse light |
||
