1. High Level Comfortable: Cabin 4 point full -floating air suspension, adjustable steering wheel with various height sand angles. air suspension seat, Cruise Constant Speed System, MINI Player .electrical control glass and mirror, TM Gearbox ,bunk with AC.
2.High Security :The key parts adopt the world's top products
3.Top configuration : Dismal brakes +EVB,ABS+ASR+EBL+TPM, More Powerful electronic management system.
4. High Quality: CNHTC's base on Strong technical support and top level technology
ruck Brand |
SINOTRUK—HOWO ( LHD) |
||||
Truck Model |
ZZ1257N5247C |
||||
Dimension(Lx W x H)(unloaded)(mm) |
11184x2496x3600 |
||||
Cargo body dimension (L x W x H)mm |
8480x2300x800 |
||||
Approaching angle/Departure angle(°) |
16/10 |
||||
Overhang(front/rear) (mm) |
1500/3109 |
||||
Wheel base (mm) |
5225+1350 |
||||
Max speed(km/h) |
90,101 |
||||
Curb weight(kg) |
11670 |
||||
Loading Weight(kg) |
25000 |
||||
Engine (Steyr technology, made in China) |
Model |
WD615.69 water-cooled,four strokes,6 cylinders in line with water cooling , directly injection |
|||
Fuel type |
Diesel |
||||
Horse Power, max(kw/rpm) |
336HP |
||||
Emission |
EURO II |
||||
Fuel tanker capacity (L) |
300 |
||||
Transmission |
Model |
HW19710,10 forwards and 2 reverse |
|||
Brake system
|
Service brake |
Dual circuit compressed air brake |
|||
Parking brake |
spring energy, compressed air operating on rear wheels |
||||
Auxiliary brake |
Engine exhaust brake |
||||
Steering system |
Model |
hydraulic steering with power assistance |
|||
Front axle |
HF7 |
||||
Rear axle |
HW12 |
||||
Color |
Optional |
||||
Tyre |
295/80R22.5 tubeless tires |
||||
Tyre quantity |
10pcs + 1 spare |
||||
Electrical system
|
Battery |
2X12V/165Ah |
|||
Alternator |
28V-1500kw |
||||
Starter |
7.5Kw/24V |
||||
Cab |
HW76 cab, one sleeper with air conditioner, all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension |
